ICAO-code: DAAG
Position: N 36 41' 28" - E 3 12' 55"
Altitude: 82 ft / 25 m
Magnetic Variation: 0,875 West





ATIS frequency are not available, in order to receive METAR contact Tower on 118.7

Clearence SID departure provided by Tower upon request

No VFR flights are allowed in and out without a current flight plan

ILS runway 09 unserviceable, clearence for visual approach via OA and normal visual traffic pattern to 09 or direct to rw09 via ALR vor.

Navaids
Type
ID
Name
Channel

Freq
Distance From Field
Bearing From Navaid
VOR
SDM
ALGER
-
113.9
12.1 NM
073.6
VOR-DME
ALR
ALGER
072X
112.5
At Field
-
NDB
SMR
HOUARI BOUMEDIENE
-
370
6.0 NM
092.0

Callsign

Frequency

Algiers Tower

 118.7

Algiers Approach

121.4/120.8

Algiers Control

127.3 Center

 Runway 05

  Runway 09

Surface
ASPHALT

 ASPHALT

Magnetic Heading
054.0

 093.0

True Heading
053.0

 092.0

Latitude
36.693906 N

36 41' 38.06" N

 36.692050 N

36 41' 31.38" N
Longitude
3.220239 E

003 13' 12.86" E

3.170811 E

003 10' 14.92" E

Elevation
71.0 feet

22 meters

56.0 feet

17 meters

Slope
0.1
0.1
Landing Distance
11483 feet

3500 meters

11483 feet

3500 meters

Takeoff Distance
11483 feet

3500 meters

11483 feet

3500 meters

Lighting System
HIRL

PAPI

PORTABLE

HIRL

PAPI

Runway 23

Runway 27

Surface
ASPHALT
ASPHALT
Magnetic Heading
234.0
273.0
True Heading
233.0

272.0

Latitude
36.712917 N

36 42' 46.50" N

36.691125 N

36 41' 28.05" N

Longitude
3.251431 E

003 15' 05.15" E

3.209933 E

003 12' 35.76" E

Elevation
81.0 feet

25 meters

66.0 feet

20 meters

Slope
-0.1
-0.1
Landing Distance
11483 feet

3500 meters

11483 feet

3500 meters

Takeoff Distance
11483 feet

3500 meters

12498 feet

3809 meters

Lighting System
HIRL

V

PAPI

PORTABLE

HIRL

PAPI



DAAA ALGER (ACC)

Attempted Translation: VOR INSTALLED ZEMMOURI MOVABLE NEW VOR INSTALLED WITH FOLLOWING CARACTERISTICS: 1 STATION: ZEMMOURI 2 SERVICE: VOR 3 CALL-SIGN: ZOULOU ECHO MIKE 4 FREQUENCY:117.05MHZ 5 COORDINATES WGS 84: 364745N 0033421E. 17 JAN 17:09 TIL 19 APR 17:09 ESTIMATED

Attempted Translation: FLIGHT INFORMATION REGION (FIR) LONGITUDINAL THE ACFT SEPARATION BETWEEN ONE THE INTERFACE OF ALGIERS/NIAMEY FIR AND ALGIERS/DAKAR FIR WILL TEN BE (MINUTES 10. 20 FEB 00:01 TIL PERM
Original Text: A0150/03 - THE LONGITUDINAL SEPARATION BETWEEN ACFT ON THE INTERFACE OF ALGIERS/NIAMEY FIR AND ALGIERS/DAKAR FIR WILL BE TEN (10 MINUTES. 20 FEB 00:01 UNTIL PERM

A0688/03 - LGT TWY G-F1-F2-E1-E2-D2-D4 UNSERVICEABLE. 16 JUL 11:44 UNTIL 13 AUG 11:44 ESTIMATED

A0696/03 - FREQ 121.8 MHZ ALGER/ SOL SUSPENDED. 21 JUL 06:27 UNTIL 07 AUG 06:27 ESTIMATED

A0560/03 - L'ATTENTE SE FERA SUR NDB ZEM 359KHZ SUR NDB MAR 416KHZ .LES SORTIES SERONT DONNEES EN CODE. L'ATTENTE SUR OA DEMEURERA RESIDUELLE. 10 JUN 20:50 UNTIL 11 SEP 20:50 ESTIMATED
